16/05/2024

Adhesive Labels
Art.-No. 557-00066 | TAGHTP-336-WH |  Details

    This product is not available anymore.
    • Very clear and detailed image for use with graphics, single or sequential characters and especially barcodes
    • Smear-resistant, ultraviolet-resistant and chemical-resistant marking
    Add to watchlist

    Request your individual offer now

     Request quote
    Application Patch Panels - Port - Standard (4 or 6 Ports)
    Application Method Each roll of labels is loaded onto a reusable spindle. Simply drop the label roll into the printer, pull the labels over the top (like loading film into a camera) and close the cover. No need to mechanically feed and align the labels.
    Colour White (WH)
    Fixation Method Pasting / Stick
    Key product features weather resistant, chemical resistance
    Local order number TAGHTP-336
    Material Type 336, Polyester, white (336)
    PART DESCRIPTION TAGHTP-336-WH
    Pack Cont. 50pcs.
    Package Content packed in Reel
    Product Group Adhesive Labels
    Type TAGHTP
    Variant Roller form
    With label space Yes
    H printable 11.28mm
    Height (H) 11.28mm
    Length (L) 11.28m
    Print Method thermal transfer print
    Width (W) 8.45mm
    Width of LIner (WL) (imperial) 1.125"
    Width of Liner (WL) 28.57mm
    Adhesive Acrylic
    Adhesive Operating Temperature -40 °C to +150 °C
    CE Certification No
    Curing Temperature from +10 °C
    Operating Temperature -40 °C to +150 °C
    ROHS compliant Yes
    Specifications
    UL OCD link Link Link
    UL Recognized (US and Canada) Yes
    UL-File Number MH18396
    Country of Origin US
    GTIN-13 / EAN 4031026230733
    Packaging 1 - Weight (kg) 0.3kg
    ETIM 7.0 Key EC001530
    ETIM 8.0 Key EC001530
    ETIM 9.0 Key EC001530
    UNSPSC Key 55121612
