Cable tie outside serrated, 370x7.6mm, ∅14.0-106mm, black, 100pcs.
Art.-No. 132-00002 | LHT370-PA66-BK Details

  • Both sides of the cable tie serrated
  • BHT-Series with round head for larger bearing area
  • BHT375 for centred position
  • CT- and DE-Series with small squared head for restricted space areas
  • Tensioning with application tool
Show more

Request your individual offer now

Application Using a single hole these 'chassis ties' are widely used in the automotive, truck and heavy equipment markets. Ideal for applications which have access to both sides of the hole - for example truck frames.
Cable Tie Polyamide 6.6 (PA66)
Colour Black (BK)
Identification Plate Position none
Key product features for direct fixation
Local order number LHT370.NB901
Material Polyamide 6.6 (PA66)
Material Head Polyamide 6.6 (PA66)
PART DESCRIPTION LHT370-PA66-BK
Pack Cont. 100pcs.
Package Content packed in Bag
Product Family Chassis ties
Product Group Cable ties for single hole application
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type LHT370
Variant Outside Serrated
Bundle Diameter max (metric) 106mm
Bundle ∅ 14.0-106mm
Bundle ∅ min. 14.0mm
Height (H) 1.8mm
Length (L) 370mm
Min.Tensile Strength 535N
Weight/Unit 0.0038kg
Width (W) 7.6mm
for Hole ∅ (FH) 8.5 mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Hazardous Goods No
Operating Temperature -40 °C to +85 °C
ROHS compliant Yes
Specifications
Country of Origin PL
Customs Number 39269097
GTIN-13 / EAN 5022660309076
Packaging 1 - Height (m) 0.13m
Packaging 1 - Length (m) 0.4m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.01664
Packaging 1 - Weight (kg) 0.3955kg
Packaging 1 - Width (m) 0.32m
Packaging 3 - Height (m) 0.184m
Packaging 3 - Length (m) 0.58m
Packaging 3 - Qty 2000
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.0406
Packaging 3 - Weight (kg) 8.51kg
Packaging 3 - Width (m) 0.38m
Packaging 4 - Height (m) 1.248m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 48000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.198
Packaging 4 - Weight (kg) 225.48kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
