Heat shrink marker, thermal transfer print, continuous, 12.0mm/4.0mm, black, 54m
Art.-No. 553-31252
| TCGT12-4BK-PO-X-BK
|
Details
- Shrink ratio 3:1
- Available in Black, Blue, Red, White, and Yellow
- Cable range from 39mm to 1mm
- Good mechanical strength and resistance to organic solvents and chemicals
- Highly flexible
- Fulfils CSA requirements
- Delivery in convenient storage boxes
- Easy label design with TagPrint Pro
Request your individual offer now
Request quote
More products in this product group:
Application | TCGT is a commercial grade 3:1 heat shrink marker material supplied as a continuous tube and printable on both sides. TCGT’s polyolefin compound has good mechanical strength and resistance to organic solvents and chemicals. The surface of the tubing has been especially prepared so that print performance is excellent at all times. HellermannTyton's printer range allow users to create a high quality print. In addition it is possible to either perforate the tubing at pre-determined lengths or fully sever the markers. |
Behaviour at low Temperature test method | ASTM D2671 |
Colour | Black (BK) |
Heat Aging Test | 168h/175°C |
Heat Aging test method | ASTM D638 |
Heat Shock Test | 4h/250°C |
Material | Polyolefin, cross-linked (PO-X) |
PART DESCRIPTION | TCGT12-4BK-PO-X-BK |
Pack Cont. | 54m |
Package Content packed in | Carton |
Printable | Yes |
Product Family | TCGT – 3:1 Commercial Grade |
Product Group | Shrinkable markers, "Continuous Tube", thermal transfer |
Short Description | Shrinkable Continuous Tube 3:1 printable black 12/4 54m/box = 3 reels |
Shrink Ratio | 3:1 |
Type | TCGT12-4BK |
Variant | Thin-Wall |
With inner glue (Yes/No) | No |
Dielectric Strength | 20kV/mm |
Dielectric Strength test method | ASTM D2671 |
ELV compliant Dir. Art. 4 (2) | YES |
Elongation at break | 300 % |
Elongation at break test method | ASTM D638 |
Halogen-free | No |
Hazardous Goods | No |
Insulation Class | B (VDE 0530) |
Minimum Shrink Temperature | +90 °C |
Operating Temperature | -55 °C to +135 °C |
ROHS compliant | Yes |
Recommended Ribbon Type | TTDTHOUT, TTRW, TT822OUT8 |
Reel Variant | continuous |
Specifications | C22.2 no. 198.1-99 |
Specifications | |
Tensile Strength | 11.00N/mm² |
Test Method Tensile Strength | ASTM D638 |
UL Listed (US and Canada) | No |
Volume Resistance | 10¹⁶ Ω cm |
Volume Resistance test method | ASTM D257 |
Water Absorption | 0.20% |
|
|
Country of Origin | PL |
Customs Number | 39173200 |
GTIN-13 / EAN | 4031026541013 |
Packaging 1 - Height (m) | 0.027m |
Packaging 1 - Length (m) | 0.16m |
Packaging 1 - Qty | 18 |
Packaging 1 - Type | Reel |
Packaging 1 - Volume (m³) | 0.00069m³ |
Packaging 1 - Weight (kg) | 0.32706kg |
Packaging 1 - Width (m) | 0.16m |
Packaging 2 - Height (m) | 0.168m |
Packaging 2 - Length (m) | 0.168m |
Packaging 2 - Qty | 54 |
Packaging 2 - Type | Carton |
Packaging 2 - Volume (m³) | 0.0031m³ |
Packaging 2 - Weight (kg) | 1.08418kg |
Packaging 2 - Width (m) | 0.11m |
Reel Length | 18m |
