Cable tie inside serrated, 530.0x8.9mm, ∅8.0-150.0mm, black, 25pcs.
Art.-No. 111-15609
| T150M-PA66HS-BK
|
Details
- Heat stabilized cable ties (PA66HS) for temperatures up to +105 °C
- Available in a wide range of sizes to cover almost every application
- Inside serration provides a strong hold onto bundles
- Manual and/or pneumatic tools available for greater process reliability
- Commonly offered in natural and black, other colors available on request
Request your individual offer now
Request quote
More products in this product group:
| Application | These inside serrated cable ties are made from heat stabilized Polyamide 6.6 (PA66HS). They can be applied in environments with continuous temperatures up to +105 °C. T-Series cable ties can be easily installed by hand or using an application tool to ensure consistency of installation. |
| Application Method | Quick, simple fixing by hand or with HellermannTyton tensioning tools |
| Colour | Black (BK) |
| Identification Plate Position | none |
| Local order number | T150M.HB1P |
| Material | Polyamide 6.6, heat stabilised (PA66HS) |
| PART DESCRIPTION | T150M-PA66HS-BK |
| Pack Cont. | 25pcs. |
| Package Content packed in | Bag |
| Product Family | T-Series in PA66HS black |
| Product Group | Cable Ties for temperatures up to + 105°C (heat stabilised) |
| Releasable Closure (Yes/No) | No |
| Short Description | Cable Tie 525x8.9 mm HS-black |
| Tie Closure | plastic pawl |
| Type | T150M |
| Variant | Inside Serrated |
Download
| CE Certification | Yes |
| CSA Certified | No |
| ELV compliant Dir. Art. 4 (2) | YES |
| Flammability | UL 94 V2 |
| Halogen-free | Yes |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +125 °C |
| Plenum Rating | AH-2 |
| ROHS compliant | Yes |
| Specifications |
|
| Specifications | UL 62275 |
| UL Listed (US and Canada) | Yes |
| UL Listed (US and Canada) | Yes |
| UL Recognized (US and Canada) | Yes |
| UL Recognized (US and Canada) | Yes |
| UL-File Number | E64139 |
| UV-Stabilised | No |
|
|
|
| Country of Origin | US |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026312071 |
| Packaging 1 - Height (m) | 0.032m |
| Packaging 1 - Length (m) | 0.557m |
| Packaging 1 - Qty | 25 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.00244m³ |
| Packaging 1 - Weight (kg) | 0.325001kg |
| Packaging 1 - Width (m) | 0.137m |
| Packaging 3 - Height (m) | 0.225425m |
| Packaging 3 - Length (m) | 0.84455m |
| Packaging 3 - Qty | 1000 |
| Packaging 3 - Type | Box |
| Packaging 3 - Volume (m³) | 0.0447m³ |
| Packaging 3 - Weight (kg) | 13.65004kg |
| Packaging 3 - Width (m) | 0.23495m |
| Packaging 4 - Height (m) | 1.269m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 15000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.218m³ |
| Packaging 4 - Weight (kg) | 225.75kg |
| Packaging 4 - Width (m) | 0.8m |
