Cable tie outside serrated, 180x9.0mm, ∅10.0-42.0mm, black, 100pcs.
Art.-No. 112-18061 | PE180-PA66HS-BK |  Details

Low profile cable ties, RPE- and PE-Series.

    • Outside serrated cable tie with a smooth surface to the bundle
    • Broad contact area with the bundle minimises risk of damage
    • Low profile head for ideal use in restricted spaces
    • Parallel entry for optimal fit around circular bundles
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads Datasheet
    Application These ties are particularly useful in areas with restricted space. The low profile design ensures that nothing snags on the heads. The outside serration of the tie with its smooth surface to the bundle avoids any damages to the insulation.
    Colour Black (BK)
    Fixation Method Others
    Identification Plate Position none
    Key product features for narrow space
    Local order number PE180.HB900
    Material Polyamide 6.6, heat stabilised (PA66HS)
    PART DESCRIPTION PE180-PA66HS-BK
    Pack Cont. 100pcs.
    Package Content packed in Bag
    Product Family PE-Series
    Product Group Cable ties with low profile head
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type PE180
    Variant Outside Serrated
    Bundle Diameter max (metric) 42.0mm
    Bundle ∅ 10.0-42.0mm
    Bundle ∅ min. 10.0mm
    Length (L) 180mm
    Min.Tensile Strength 445N
    Width (W) 9.0mm
    Flammability UL 94 V2
    Operating Temperature -40 °C to +105 °C, (+105 °C for 500 h)
    ROHS compliant Yes
    Specifications
    Specifications IEC 60092 series
    Country of Origin GB
    GTIN-13 / EAN 5022660313738
    Packaging 3 - Height (m) 0.192m
    Packaging 3 - Length (m) 0.586m
    Packaging 3 - Type Box
    Packaging 3 - Volume (m³) 0.0439m³
    Packaging 3 - Width (m) 0.39m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
