Fixing tie for stud, outside serrated, ∅3.0-45.0mm, black, 500pcs.
Art.-No. 156-00116 | T50ROSGBS8C-C-PA66HS/PA66HIRHS-BK |  Details

GBS8C

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads CAD-Download Datasheet
    Colour Black (BK)
    Identification Plate Position none
    Local order number T50ROSGBS8C.HB9
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    No. of sides for tie attachment 1
    PART DESCRIPTION T50ROSGBS8C-C-PA66HS/PA66HIRHS-BK
    Pack Cont. 500pcs.
    Package Content packed in Bag
    Type T50ROSGBS8C-C
    Variant Outside Serrated
    Bundle Diameter max (metric) 45.0mm
    Bundle ∅ 3.0-45.0mm
    Bundle ∅ min. 3.0mm
    Height (H) 1.3mm
    Height (H2) 20.0mm
    Length (L) 200mm
    Max Stud Length 19.0mm
    Min.Tensile Strength 225N
    Stud ∅ 8.0 mm
    Thickness (T) 1.3mm
    Weight/Unit 0.004kg
    Width (W) 4.6mm
    ELV compliant Dir. Art. 4 (2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C, (+105 °C for 500 h)
    ROHS compliant Yes
    Specifications
    Country of Origin PL
    Customs Number 39269097
    GTIN-13 / EAN 4031026260167
    Packaging 1 - Height (m) 0.095m
    Packaging 1 - Length (m) 0.47m
    Packaging 1 - Qty 500
    Packaging 1 - Type Bag
    Packaging 1 - Volume (m³) 0.02433m³
    Packaging 1 - Weight (kg) 2.043597kg
    Packaging 1 - Width (m) 0.545m
    Packaging 3 - Height (m) 0.368m
    Packaging 3 - Length (m) 0.584m
    Packaging 3 - Qty 2000
    Packaging 3 - Type Box
    Packaging 3 - Volume (m³) 0.083m³
    Packaging 3 - Weight (kg) 8.994388kg
    Packaging 3 - Width (m) 0.386m
    Packaging 4 - Height (m) 1.248m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 24000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.198m³
    Packaging 4 - Weight (kg) 128.952kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...
