Connector clip for hole (oval), black, 1000pcs.
Art.-No. 133-01073 | CCPAEDOP6.0x12.0-PA66HIRHS-BK Details

Request your individual offer now

Colour Black (BK)
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION CCPAEDOP6.0x12.0-PA66HIRHS-BK
Pack Cont. 1000pcs.
Package Content packed in Bag
Short Description Connector Clip 0,6 - 6 mm, high impact modified, heat stabilised, black
Type CCPAEDOP6.0x12.0
Height (H) 17.5mm
Length (L) 20.0mm
Weight/Unit 0.001222kg
Width (W) 22.5mm
for Hole ∅ (FH) 6.2 x 12.2 mm
for Panel Thickness min - max 0.6 - 6 mm
ELV compliant Dir. Art. 4 (2) YES
Hazardous Goods No
Operating Temperature -40 °C to +105 °C, (+105 °C for 500 h)
ROHS compliant Yes
Specifications
Country of Origin DE
Customs Number 39269097
GTIN-13 / EAN 4031026457963
Packaging 1 - Height (m) 0.065m
Packaging 1 - Length (m) 0.29m
Packaging 1 - Qty 1000
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00641
Packaging 1 - Weight (kg) 1.243815kg
Packaging 1 - Width (m) 0.34m
Packaging 3 - Height (m) 0.184m
Packaging 3 - Length (m) 0.58m
Packaging 3 - Qty 4000
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.0406
Packaging 3 - Weight (kg) 5.57526kg
Packaging 3 - Width (m) 0.38m
Packaging 4 - Height (m) 1.248m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 96000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.198
Packaging 4 - Weight (kg) 154.824kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000127
ETIM 8.0 Key EC000127
ETIM 9.0 Key EC000127
UNSPSC Key 39121702
