Blind plug, ∅20.0 x 50.0 mm, black, 1500pcs.
Art.-No. 151-00342 | Cover Plug 20x50-PP/EPDM-BK Details

  • Easy assembly without the need of a tool
  • Protection of ingress of dust, dirt and water are offered by cover plug

Request your individual offer now

Application Products were developed especially for the automotive industry. Application in trunks, doors, wheel housing and dash panels particularly where holes have to be covered to be secured against dirt and dust. Parts are even used for optical reasons.
Colour Black (BK)
Local order number 17203
Material Polypropylene (PP), Ethylene Propylene Diene Terpolymer rubber free of Nitrosamine (EPDM)
PART DESCRIPTION Cover Plug 20x50-PP/EPDM-BK
Pack Cont. 1500pcs.
Package Content packed in Carton
Product Group Cover Plugs and Open Plugs
Type Cover Plug 20x50
Weight/Unit 0.003273kg
for Hole ∅ (FH) 20.0 x 50.0 mm
for Panel Thickness min - max 2.5 - 2.5 mm
ELV compliant Dir. Art. 4 (2) YES
Hazardous Goods No
Operating Temperature -20 °C to +95 °C
ROHS compliant Yes
Specifications
Country of Origin FR
Customs Number 39269097
GTIN-13 / EAN 4031026337647
Packaging 3 - Height (m) 0.3m
Packaging 3 - Length (m) 0.4m
Packaging 3 - Qty 1500
Packaging 3 - Type Box
Packaging 3 - Volume (m³) 0.036
Packaging 3 - Weight (kg) 5.4045kg
Packaging 3 - Width (m) 0.3m
Packaging 4 - Height (m) 1.044m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 36000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.002
Packaging 4 - Weight (kg) 150.708kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000127
ETIM 8.0 Key EC000127
ETIM 9.0 Key EC000127
UNSPSC Key 39121702
