Cable clip for stud, Dmax=13.5mm, ∅5.0 mm
Art.-No. 150-47700
| SBF2-PA66-BK
|
Details
- One-piece fixing and retainer
- For bundles of up to 13.5 mm
- Retainer releasable for easy maintenance or post-installation of cables
- Two additional holders for firm hold of smaller bundles
Request your individual offer now
Request quote
More products in this product group:
| Application | Many industries (but specifically the automotive market) are using 'weld studs' as the standard method of attaching components. Simply hammered onto the stud these parts provide ideal fixing bases for attaching cables, pipes or hose. The use of weld studs avoids the problems with 'holes' (ingress of moisture, corrosion etc). |
| Colour | Black (BK) |
| Fixation Method | Weld Stud Fixing |
| Key product features | lockable, rotatable |
| Local order number | SBF2.NB6P |
| Material | Polyamide 6.6 (PA66) |
| PART DESCRIPTION | SBF2-PA66-BK |
| Pack Cont. | 500pcs. |
| Package Content packed in | Bag |
| Product Family | SBF-Clips |
| Product Group | Fixing Elements for Weld Studs |
| Short Description | Fixing Clip 47.7x18.2 mm, for Weld Studs, black |
| Type | SBF2 |
Download
|
|
|
| Country of Origin | DE |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026121093 |
| Packaging 1 - Height (m) | 0.3m |
| Packaging 1 - Length (m) | 0.625m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.0825m³ |
| Packaging 1 - Weight (kg) | 1.437478kg |
| Packaging 1 - Width (m) | 0.44m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 6000 |
| Packaging 3 - Type | Box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 18.069736kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.248m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 72000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.198m³ |
| Packaging 4 - Weight (kg) | 237.768kg |
| Packaging 4 - Width (m) | 0.8m |
