12/03/2025

Connector clip, black, 500pcs.
Art.-No. 151-00708 | YCCKSFT62x122-PA66HIRHS-BK |

Copied

    This product is not available anymore.
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads CAD-Download
    Colour Black (BK)
    Fixation Method Arrowhead for oval holes
    Local order number YCCKSFT6.5x122_HIRHS_D1
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION YCCKSFT62x122-PA66HIRHS-BK
    Pack Cont. 500pcs.
    Package Content packed in Bag
    Product Group Connector Clips for oval holes
    Type YCCKSFT62x122
    Weight/Unit 0.00085kg
    for Hole ⌀ (FH) 6.2 x 12.2 mm
    for Panel Thickness min - max 0.7 - 1.2 mm
    ELV compliant Dir. Art. 4 (2) YES
    Flammability UL 94 HB
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C, (+105 °C for 500 h)
    ROHS compliant Yes
    Specifications
    Country of Origin FR
    Customs Number 39269097
    GTIN-13 / EAN 4031026311562
    Packaging 1 - Height (m) 0.3m
    Packaging 1 - Length (m) 0.625m
    Packaging 1 - Qty 500
    Packaging 1 - Type Bag
    Packaging 1 - Volume (m³) 0.0825m³
    Packaging 1 - Weight (kg) 0.478478kg
    Packaging 1 - Width (m) 0.44m
    Packaging 3 - Height (m) 0.204m
    Packaging 3 - Length (m) 0.591m
    Packaging 3 - Qty 8000
    Packaging 3 - Type Box
    Packaging 3 - Volume (m³) 0.048m³
    Packaging 3 - Weight (kg) 8.617648kg
    Packaging 3 - Width (m) 0.398m
    Packaging 4 - Height (m) 1.204m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 160000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.156m³
    Packaging 4 - Weight (kg) 193.2kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 31162305
