Label, yellow, manual marking, 11.00x19.00mm, 440pcs.
Art.-No. 598-92427
| TAG124FB-270-YE
|
Details
- Yellow fabric adhesive labels
- Supplied in handy pocket-sized booklets
- Booklet cover protects labels when stored
- Easily remove or reposition labels as required
- No sticky residue on removal
- Labels available with or without black border
- Also suitable for difficult surfaces
- Use T82 marker pen for market leading mark endurance
Request your individual offer now
Request quote
More products in this product group:
| Application | These handwritten labels are made of yellow fabric and have been designed for fast on-site identification of component parts, switching devices and other operating equipment. The synthetic rubber adhesive allows the easy removal or repositioning of the label when needed. For professional handwriting we recommend the marking pen T82, equipped with a fast-drying and UV-resistant ink. |
| Application Method | The functionality and durability of the labels can be negatively affected if improperly processed or applied. All surfaces to be bonded must be clean, dry as well as free from dust and grease. Avoid touching the adhesive surface of the label as this could impair the application performance. |
| Chem. Material Properties | Good resistance to water, oils and most solvents, alcohols and gasoline. |
| Colour | Yellow (YE) |
| Colour Marking Field | Yellow (YE) |
| Description | With border |
| Key product features | removable |
| Material | Type 270, Cotton cloth, yellow (270) |
| PART DESCRIPTION | TAG124FB-270-YE |
| Pack Cont. | 440pcs. |
| Package Content packed in | Pack |
| Product Family | HELASIGN, Material 270 (Yellow), Booklet |
| Product Group | Cotton cloth labels, manual marking |
| Self adhesive (Yes/No) | Yes |
| Short Description | Cotton cloth labels for manual marking 11x19mm yellow |
| Type | TAG124FB |
Download
| Adhesive | Synthetic rubber |
| Curing Temperature | from +10 °C |
| ELV compliant Dir. Art. 4 (2) | YES |
| Halogen-free | No |
| Hazardous Goods | No |
| Initial tack | 900g/cm² |
| Initial tack | ASTM D2979 |
| Operating Temperature | -29 °C to +80 °C |
| Peel strength | 940 N/m |
| Peel strength test method | PSTC 7 |
| Pre-Printed | No |
| ROHS compliant | Yes |
| Shelf Life | Minimum 1 year upon receipt / maximal 2 years after production date. |
| Specifications |
|
|
|
|
| Country of Origin | DE |
| Customs Number | 58071090 |
| GTIN-13 / EAN | 4031026183657 |
| Labels per Row | 4pcs. |
| Labels per Sheet | 44pcs. |
| Packaging 1 - Height (m) | 0.015m |
| Packaging 1 - Length (m) | 0.19m |
| Packaging 1 - Qty | 440 |
| Packaging 1 - Type | Pack |
| Packaging 1 - Volume (m³) | 0.00028m³ |
| Packaging 1 - Weight (kg) | 0.047kg |
| Packaging 1 - Width (m) | 0.098m |
| Sheets per Pack | 10 |
| Storage Temperature | +21 °C |
| Storage conditions | 50% relative humidity., The storage in the original packaging is recommended., Please avoid warehousing under impacts such as high humidity, heat and coldness. |
