12 Way Modular Zone Termination Box Loaded with 12 x HTC CAT6 UTP Tool Free Jacks
Art.-No. 854-20033
| ZTB12J6BKXXXX/GY
|
Details
- Supports Category 6A, Category 6 and Fibre
- Uses Hellermantytons Modular Connectivity Cat6 Keystone Jacks
- Accepts up to 12 cable lines
- 1.5mm Mild Steel for added strength
- Internal Steel cross-member supports for increased impact resistance
- Compact size allows for installation in restricted spaces
- Removeable lid for ease of termination / installation
- Lockable for security
- Fixings points to allow for installation on walls/risers, in ceilings, floor or under desk
- Grey powder coated finish for humidity and temperature protection
- Brush strips for easy cable entry/exit and debris free operation
- Integral cable anchor points
- Port identification
Request your individual offer now
Request quote
More products in this product group:
PART DESCRIPTION | ZTB12J6BKXXXX/GY |
Performance Category | Category 6 (Class E), Modular |
Port count | 12 |
Product Family | Consolidation Points and Enclosures |
Product Group | Modular Zone Termination Box CAT6 UTP |
Short Description | 12 Way Modular Zone Termination Box Loaded with 12 x HTC CAT6 UTP Tool Free Jacks |
Technical Description | The Modular Zone Termination Box (ZTB) is a compact and robust internal consolidation point. The ZTB has been designed to work as part of a Zone Cabling topology which allows for more flexibility in regards to MAC’s within a structured cabling network. This modular version of the ZTB allows for the use of HellermannTyton keystone jacks and fibre adaptors, making it easier to configure each box to your bespoke requirements giving even greater flexibility. Pre-loaded with HTC CAT6 UTP Tool Free Jacks |
Type | ZTB12J6BKXXXX/GY |
