Cable grommet, natural, 2000pcs.
Art.-No. 631-58289 | OP4828-PE-NA |  Details

Push-on caps and elbow grommets in various dimensions.

    • Protects effectively against spraying water
    • Flexible and easy to apply
    • High resistance to chemicals and environmental influences
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads Datasheet
    Application The protective push-on caps and elbow grommets are specially constructed to insulate and protect flat pin bushings. The caps and grommets are used in all areas of automotive electronics and in electrical connection systems.
    Cable ∅ max 4.0mm
    Cable ∅ min 2.2mm
    Colour Natural (NA)
    Material Polyethylene (PE)
    PART DESCRIPTION OP4828-PE-NA
    Pack Cont. 2000pcs.
    Package Content packed in pcs.
    Product Family OP4828
    Product Group Push-on Caps
    Short Description Push-on Caps natural
    Type OP4828
    Variant Open
    Diameter (D) 4.0mm
    Length (L) 18.0mm
    Outside Ø (OD) 5.2mm
    Outside ∅ (OD2) 4.0mm
    Shore Hardness A Nom. 45
    Weight/Unit 0.0001kg
    ∅ (D2) 2.8mm
    ELV compliant Dir. Art. 4 (2) YES
    Flammability UL 94 HB
    Halogen-free Yes
    Hazardous Goods No
    Nato number 5975-12-308-3734
    Operating Temperature -10 °C to +70 °C
    ROHS compliant Yes
    Specifications
    Country of Origin DE
    Customs Number 39269097
    GTIN-13 / EAN 4031026185965
    Packaging 1 - Height (m) 0.15m
    Packaging 1 - Length (m) 0.3m
    Packaging 1 - Qty 2000
    Packaging 1 - Type Bag
    Packaging 1 - Volume (m³) 0.0117m³
    Packaging 1 - Weight (kg) 0.213862kg
    Packaging 1 - Width (m) 0.26m
    ETIM 7.0 Key EC000879
    ETIM 8.0 Key EC000879
    ETIM 9.0 Key EC000879
    Cable grommets Cable grommets

    Cable grommets

    Wether snap in cable grommets, grommet strips, assortment boxes, grommets for strain relief or bend protection: Find now the right cable grommets for your application.
