Heat Shrinkable Tubing 2:1 flame retardant halogen free 6.4/3.2 black
Art.-No. 315-50640
| TR27-6.4/3.2-PO-X-BK
|
Details
- Thin wall, flexible polyolefin tubing
- Optional available with adhesive or as thick wall version (SR27)
- Halogen free and excellent flame-retardant properties
- Limited Fire Hazard
- Low generation of toxic gases and corrosive acid
- Low smoke generation
- Meets various industrial standards
Request your individual offer now
Request quote
More products in this product group:
| Application | TR27 is used in applications where toxic emissions evolved in a fire must be minimised, e.g. heavily populated buildings or safety sensitive areas like tunnels, hospitals, schools, theatres, mass transit vehicles and computer centres. |
| Behaviour at Heat Shock | not cracking, not dripping, not fluid |
| Colour | Black (BK) |
| Heat Shock Test | 4h/150°C |
| Local order number | TR27-6.4/3.2 |
| Material | Polyolefin, cross-linked (PO-X) |
| PART DESCRIPTION | TR27-6.4/3.2-PO-X-BK |
| Pack Cont. | 60m |
| Package Content packed in | metre |
| Printable | No |
| Product Family | TR27 |
| Product Group | Heat Shrinkable Tubing 2:1 - Flame retardant |
| Short Description | Heat Shrinkable Tubing 2:1 flame retardant halogen free 6.4/3.2 black |
| Shrink Ratio | 2:1 |
| Size (imperial) | 1/4" |
| Type | TR27-6.4/3.2 |
| Variant | Thin-Wall |
| With inner glue (Yes/No) | No |
Download
| Dielectric Strength | 15kV/mm |
| Dielectric Strength test method | IEC 684 P2 |
| ELV compliant Dir. Art. 4 (2) | YES |
| Elongation at break | 200% |
| Halogen-free | Yes |
| Hazardous Goods | No |
| Limited Fire Hazard | Yes |
| Minimum Shrink Temperature | +115 °C |
| Operating Temperature | -40 °C to +105 °C, (+105 °C for 500 h) |
| ROHS compliant | Yes |
| Self extinguishing | Yes |
| Specifications |
|
| Specifications | EN 45545-2 |
| Tensile Strength | 7MPa |
| Volume Resistance | 10¹³ Ω cm |
| Water Absorption | 1.0% |
| Country of Origin | JP |
| Customs Number | 39173200 |
| GTIN-13 / EAN | 4031026224626 |
| Packaging 1 - Height (m) | 0.095m |
| Packaging 1 - Length (m) | 0.39m |
| Packaging 1 - Qty | 60 |
| Packaging 1 - Type | Reel |
| Packaging 1 - Volume (m³) | 0.01445m³ |
| Packaging 1 - Weight (kg) | 1.374kg |
| Packaging 1 - Width (m) | 0.39m |
| Packaging 3 - Height (m) | 0.11m |
| Packaging 3 - Length (m) | 0.4m |
| Packaging 3 - Qty | 60 |
| Packaging 3 - Type | Carton |
| Packaging 3 - Volume (m³) | 0.0176m³ |
| Packaging 3 - Weight (kg) | 1.874kg |
| Packaging 3 - Width (m) | 0.4m |
| Packaging 4 - Height (m) | 1.024m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 2880 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 0.983m³ |
| Packaging 4 - Weight (kg) | 110.952kg |
| Packaging 4 - Width (m) | 0.8m |
| Reel Length | 60.0m |
