T-Shape VG-Style black, PO-X
Art.-No. 412-07180 | 1207-1-G-PO-X-BK | Details

1202-1-G recovered onto a cable harness.

4-way outlet shape
Cable sealing, strain relief and mechanical protection

Add to watchlist

Request your individual offer now

Request quote

Distributors near you

Downloads CAD-Download

More products in this product group:

T-Shapes, VG style/MIL style >

Base Data

Application	Heat Shrinkable moulded shapes for use in Electrical and Electronic Cable Harness Applications.
Colour	Black (BK)
Local order number	VG95343T08A011A
Material	Polyolefin, cross-linked (PO-X)
PART DESCRIPTION	1207-1-G-PO-X-BK
Pack Cont.	1pc.
Package Content packed in	pcs.
Product Family	Helashrink 1200 Series
Product Group	T-Shapes, VG style/MIL style
Short Description	T-Shape VG-Style black, PO-X
Type	1207-1-G
Variant	For 2-core cables

Product Dimensions


Flexibility	Semi rigid
HW ± 20%	2.5mm
HW ± 30%	2.5mm
JW ± 20%	2.5mm
JW ± 30%	2.5mm
KW ± 20 %	2.5mm
M nom	20.0mm
P ± 10%	120.0mm
R ± 10%	60mm
S ± 10%	59.9mm
Weight/Unit	0.03kg
∅H max b	13.5mm
∅H min a	27.0mm
∅J max b	13.5mm
∅J min. a	27.0mm
∅K max. b	13.5mm
∅K min. a	27.0mm

Downloads

Specifications

Designation as per VG-Norm	VG 95343 T08 A 011 A
Dielectric Strength	14kV/mm
Dielectric Strength test method	ASTM D2671
ELV compliant Dir. Art. 4 (2)	YES
Flammability	ASTM D635
Hazardous Goods	No
Minimum Shrink Temperature	+135 °C
Nato number	5970-12-306-3735
Operating Temperature	-75 °C to +150 °C
ROHS compliant	Yes
Shelf Life	5 years
Specifications
Specifications	VG 95343-8:2016-03

Logistics and Packaging


Country of Origin	GB
Customs Number	39174000
GTIN-13 / EAN	5022660635397
Packaging 1 - Height (m)	0.03m
Packaging 1 - Length (m)	0.13m
Packaging 1 - Qty	1
Packaging 1 - Type	Bag
Packaging 1 - Volume (m³)	0.00039m³
Packaging 1 - Weight (kg)	0.030001kg
Packaging 1 - Width (m)	0.1m

More Information

ETIM 7.0 Key	EC002464
ETIM 8.0 Key	EC002464
ETIM 9.0 Key	EC002464
UNSPSC Key	39121721
