Heat shrink marker, thermal transfer print, ladder-style, 19.70mm/9.6mm, W=50.0mm, yellow, 1500pcs.
Art.-No. 533-65030
| TLFD190DS-1X50YE-PO-X-YE
|
Details
- Shrink ratio 2:1
- Halogen free and fluid resistant
- Low smoke propagation and toxicity
- Fluid resistant
- "Ladder Style" format for ease of use
- Available in yellow and white
- 50 mm and 25 mm pre-cut markers as standard
Request your individual offer now
Request quote
More products in this product group:
| Application | TLFD DS is an innovative 2:1 heat shrink marker which is halogen free, low fire hazard and fluid resistant. This rail and EN approved material is supplied pre-cut and formatted into a convenient "ladder" system. The TLFD DS marker’s material properties are ideal for applications where fire protection is of great importance. TLFD DS shows low smoke propagation, density and toxicity and is also ideal for applications where resistance to organic fluids, common fuels, lubricants and solvents properties are required. The pre-cut format not only allows printing on both sides of the marker but the user can also easily choose and pick each required marker. The tubing has been especially prepared so that the print performance is excellent at all times using HellermannTyton's printer range. |
| Colour | Yellow (YE) |
| Fixation Method | Suspend |
| Local order number | TLFD190DS-1X50YE |
| Material | Polyolefin, cross-linked (PO-X) |
| PART DESCRIPTION | TLFD190DS-1X50YE-PO-X-YE |
| Pack Cont. | 1500pcs. |
| Package Content packed in | Carton |
| Printable | Yes |
| Product Family | TLFD DS – 2:1 Rail Limited Fire Hazard, fluid resistant "Ladder Style" |
| Product Group | Shrinkable markers "Ladder Style", thermal transfer |
| Short Description | Shrinkable markers ladder style, thermal transfer, 2:1 (19.0 mm/9.5 mm) yellow 50 mm, 1500 pcs. |
| Shrink Ratio | 2:1 |
| Type | TLFD190DS-1X50YE |
| Variant | Roller form |
| With inner glue (Yes/No) | No |
| With label space | Yes |
Download
| Dielectric Strength | 19.7kV/mm |
| ELV compliant Dir. Art. 4 (2) | YES |
| Halogen-free | Yes |
| Hazardous Goods | No |
| Limited Fire Hazard | Yes |
| Minimum Shrink Temperature | +120 °C |
| Operating Temperature | -55 °C to +125 °C |
| ROHS compliant | Yes |
| Recommended Ribbon Type | TTDTHOUT |
| Reel Variant | ladder-style |
| Shelf Life | 24 months |
| Specifications |
|
| Specifications | DIN EN 50343:2014 Appendix H, EN 45545-2 |
|
|
|
| Country of Origin | DK |
| Customs Number | 39173200 |
| GTIN-13 / EAN | 4031026592695 |
| Packaging 1 - Height (m) | 0.098m |
| Packaging 1 - Length (m) | 0.3m |
| Packaging 1 - Qty | 1500 |
| Packaging 1 - Type | Reel |
| Packaging 1 - Volume (m³) | 0.00882m³ |
| Packaging 1 - Weight (kg) | 2.337kg |
| Packaging 1 - Width (m) | 0.3m |
| Packaging 2 - Height (m) | 0.118m |
| Packaging 2 - Length (m) | 0.334m |
| Packaging 2 - Qty | 1500 |
| Packaging 2 - Type | Carton |
| Packaging 2 - Volume (m³) | 0.0125m³ |
| Packaging 2 - Weight (kg) | 2.684kg |
| Packaging 2 - Width (m) | 0.318m |
| Storage conditions | 50% relative humidity., The storage in the original packaging is recommended., Please avoid warehousing under impacts such as high humidity, heat and coldness. |
