Heat shrink marker, thermal transfer print, continuous, 39.0mm/13.0mm, yellow, 10m
Art.-No. 553-43950
| TULT39-13YE-PO-X-YE
|
Details
- Shrink ratio 3:1
- Available in black, blue, red, white and yellow
- Cable range from 39 mm to 1 mm
- Good mechanical strength and resistance to organic solvents and chemicals
- Highly flexible
- Delivery in convenient storage boxes
Request your individual offer now
Request quote
More products in this product group:
| Application | TULT is a UL recognized 3:1 heat shrink marker material supplied as a continuous tube and printable on both sides. TULT’s polyolefin compound has good mechanical strength and resistance to organic solvents and chemicals. The surface of the tubing has been especially prepared so that print performance is excellent at all times. HellermannTyton's printer range allow users to create a high quality print. In addition it is possible to either perforate the tubing at pre-determined lengths or fully sever the markers. |
| Behaviour at low Temperature test method | ASTM D2671 |
| Colour | Yellow (YE) |
| Heat Aging Test | 168h/175°C |
| Heat Aging test method | ASTM D638 |
| Heat Shock Test | 4h/250°C |
| Local order number | TULT39-13 |
| Material | Polyolefin, cross-linked (PO-X) |
| PART DESCRIPTION | TULT39-13YE-PO-X-YE |
| Pack Cont. | 10m |
| Package Content packed in | Carton |
| Printable | Yes |
| Product Family | TULT – 3:1 Military and Electronics |
| Product Group | Shrinkable markers "Continuous Tube", thermal transfer |
| Short Description | Shrinkable Marker 3:1 (39/13 mm), UL-recognized, printable, yellow, 10m/box = 1 reel |
| Shrink Ratio | 3:1 |
| Type | TULT39-13YE |
| Variant | Thin-Wall |
| With inner glue (Yes/No) | No |
Download
| CSA Certified | Yes |
| Dielectric Strength | 20kV/mm |
| Dielectric Strength test method | ASTM D2671 |
| ELV compliant Dir. Art. 4 (2) | YES |
| Elongation at break | 300 % |
| Elongation at break test method | ASTM D638 |
| Flammability | UL 224 VW-1 |
| Halogen-free | No |
| Hazardous Goods | No |
| Insulation Class | B (VDE 0530) |
| Minimum Shrink Temperature | +90 °C |
| Operating Temperature | -55 °C to +135 °C |
| ROHS compliant | Yes |
| Recommended Ribbon Type | TTDTHOUT, TTRW, TT822OUT8 |
| Reel Variant | continuous |
| Specifications | ANSI/UL 224, C22.2 no. 198.1-99 |
| Specifications |
|
| Tensile Strength | 11.00N/mm² |
| Test Method Tensile Strength | ASTM D638 |
| UL Listed (US and Canada) | No |
| UL OCD link | Link Link |
| UL-File Number | E143529 |
| Volume Resistance | 10¹⁶ Ω cm |
| Volume Resistance test method | ASTM D257 |
| Water Absorption | 0.20% |
|
|
|
| Country of Origin | PL |
| Customs Number | 39173200 |
| GTIN-13 / EAN | 4031026541747 |
| Packaging 1 - Height (m) | 0.072m |
| Packaging 1 - Length (m) | 0.16m |
| Packaging 1 - Qty | 10 |
| Packaging 1 - Type | Reel |
| Packaging 1 - Volume (m³) | 0.00184m³ |
| Packaging 1 - Weight (kg) | 0.781kg |
| Packaging 1 - Width (m) | 0.16m |
| Packaging 2 - Height (m) | 0.168m |
| Packaging 2 - Length (m) | 0.168m |
| Packaging 2 - Qty | 10 |
| Packaging 2 - Type | Carton |
| Packaging 2 - Volume (m³) | 0.0031m³ |
| Packaging 2 - Weight (kg) | 0.884kg |
| Packaging 2 - Width (m) | 0.11m |
| Reel Length | 10m |
