Fixing tie for hole (round), ∅1.0-27.0mm, natural, 100pcs.
Art.-No. 115-01900
| RT18RSF-PA66-NA
|
Details
- Easy to assemble without the need for a tool
- Cable tie head always situated in defined position
- Arrowhead simply locks into place
- Supporting legs provide a secure and firm fixing in areas where space is limited
- Releasable and therefor reusable
Request your individual offer now
Request quote
More products in this product group:
| Application | With a diverse range of fixing possibilities are ideal for use in many different industries, including automotive, aerospace and panel building. |
| Colour | Natural (NA) |
| Fixation Method | arrowhead |
| Identification Plate Position | none |
| Key product features | releasable |
| Local order number | RT18RSF.NN3P |
| Material | Polyamide 6.6 (PA66) |
| PART DESCRIPTION | RT18RSF-PA66-NA |
| Pack Cont. | 100pcs. |
| Package Content packed in | Bag |
| Product Family | for round holes, releasable |
| Product Group | 1-piece fixing ties with arrowhead, with wings |
| Releasable Closure (Yes/No) | Yes |
| Short Description | 1-piece fixing tie 132x3 mm, with arrowhead and wings, releasable, for round holes, natural |
| Type | RT18RSF |
| Bundle Diameter max (metric) | 27.0mm |
| Bundle ∅ | 1.0-27.0mm |
| Bundle ∅ min. | 1.0mm |
| Disc ∅ | 11.0mm |
| Height (H2) | 5.5mm |
| Length (L) | 132mm |
| Length (L2) | 14.80mm |
| Min.Tensile Strength | 80N |
| Thickness (T) | 1.1mm |
| Weight/Unit | 0.00065kg |
| Width (W) | 3.0mm |
| Width (W2) | 5.5mm |
| Width (W3) | 11.0mm |
| for Hole ∅ (FH) | 3.8 - 4.2 mm |
| for Panel Thickness min - max | 0.6 - 2.3 mm |
Download
| ELV compliant Dir. Art. 4 (2) | YES |
| Flammability | UL 94 V2 |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +85 °C |
| ROHS compliant | Yes |
| Specifications |
|
| Specifications | ANSI/UL 1565, ANSI/UL 62275 |
| UL OCD link | Link |
| UL Recognized (US and Canada) | Yes |
| UL-File Number | E64962 |
|
|
|
| Country of Origin | JP |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4944387210002 |
| Packaging 1 - Height (m) | 0.03m |
| Packaging 1 - Length (m) | 0.175m |
| Packaging 1 - Qty | 100 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.00071m³ |
| Packaging 1 - Weight (kg) | 0.065001kg |
| Packaging 1 - Width (m) | 0.135m |
| Packaging 3 - Height (m) | 0.345m |
| Packaging 3 - Length (m) | 0.455m |
| Packaging 3 - Qty | 10000 |
| Packaging 3 - Type | Box |
| Packaging 3 - Volume (m³) | 0.0494m³ |
| Packaging 3 - Weight (kg) | 6.9401kg |
| Packaging 3 - Width (m) | 0.315m |
| Packaging 4 - Height (m) | 1.179m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 150000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.132m³ |
| Packaging 4 - Weight (kg) | 125.1kg |
| Packaging 4 - Width (m) | 0.8m |
