Fixing tie for hole (round), inside serrated, ⌀45.0mm, black, 500Bag
Art.-No. 156-03276
| T50RSOC13.9FT6.5-PA66HIRHS-BK
|
Copied
- Pre-assembled 2-piece fixing tie with fir tree foot part
- Cable tie head can be moved after bundling
- Easy to assemble without the need for a tool
- Disc adjusts tie for pressure from various directions and minimises access of dust, dirt and water
- Fir tree foot part can be used for a variety of panel thicknesses
- Suitable for use within threaded holes
Request your individual offer now
Request quote
More products in this product group:
| Application | Primarily designed for fixing cable harnesses in the automotive industry, their simplicity and ease of use, has resulted in these parts being used in many industries, for example: aviation, switch gear manufacture and white goods. |
| Colour | Black (BK) |
| Fixation Method | Fir tree for round holes |
| Identification Plate Position | none |
| Key product features | ergonomic design |
| Local order number | T50RSOC13.9FT6.5-PA66HIRHS-BK |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | T50RSOC13.9FT6.5-PA66HIRHS-BK |
| Pack Cont. | 500Bag |
| Package Content packed in | Bag |
| Product Family | 2-Pieces Fixing Ties with Fir Tree, with Disc, for Oval Holes |
| Product Group | 2-Pieces Fixing Ties with Fir Tree, with Disc |
| Releasable Closure (Yes/No) | No |
| Tie Closure | plastic pawl |
| Type | T50RSOC13.9FT6.5 |
| Bundle ⌀ | 45.0mm |
| Bundle ⌀ max. | 45.0mm |
| Fixing Hole Shape | Hexagon, Circular |
| Height (H) | 1.2mm |
| Height (H2) | 18.4mm |
| Length (L) | 202.0mm |
| Length (L2) | 25.5mm |
| Min.Tensile Strength | 225N |
| Offset Length | 13.9mm |
| Panel Thickness max. | 0.7 - 3.0mm |
| Thickness (T) | 1.2mm |
| Weight/Unit | 0.002998kg |
| Width (W) | 4.6mm |
| Width (W2) | 15.0mm |
| for Hole ⌀ (FH) | 6.1 - 6.9 mm, M8 x 1.25 Threaded, 6.1 - 6.6 mm (hexagonal) |
| for Panel Thickness min - max | 0.7 - 3 mm |
Download
|
|
|
| Country of Origin | PL |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026734606 |
| Packaging 1 - Height (m) | 0.08m |
| Packaging 1 - Length (m) | 0.55m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.0209m³ |
| Packaging 1 - Weight (kg) | 1.542597kg |
| Packaging 1 - Width (m) | 0.475m |
| Packaging 3 - Height (m) | 0.538m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 3500 |
| Packaging 3 - Type | Box |
| Packaging 3 - Volume (m³) | 0.1213m³ |
| Packaging 3 - Weight (kg) | 11.898179kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.22m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 28000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.171m³ |
| Packaging 4 - Weight (kg) | 116.208kg |
| Packaging 4 - Width (m) | 0.8m |
