Protection cap for connectors, black, 1100pcs.
Art.-No. 151-00214
| CP31DOP-PA66HIRHS-BK
|
Details
- Meets car makers' specifications
- Hides functions not used on vehicle
- Secures electronic and electric connections for optional functions
- Used in conjunction with FCI Sicma Mini Sealed connectors
- Suitable for TYCO HP wire-to-wire connectors 2, 3 or 6 ways
- Protect seals of electrical connections
- Ensures fixation on oval or circular hole on car body
Request your individual offer now
Request quote
More products in this product group:
| Application | Compatible in the engine area for 2 and 3 ways, these parts can be fitted directly on the connector by the harnessmakers or on car line production. |
| Colour | Black (BK) |
| Fixation Method | Fir Tree for oval holes |
| Local order number | 8200554414.N5HSTTLP |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | CP31DOP-PA66HIRHS-BK |
| Pack Cont. | 1100pcs. |
| Package Content packed in | Carton |
| Product Family | with fir tree |
| Product Group | Connector Clips for oval holes |
| Short Description | Connector Clip, oval hole 6.2 x 12.2 mm, fir tree, high impact modified, heat stabilised, black |
| Type | CP31DOP |
Download
|
|
|
| Country of Origin | FR |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026333823 |
| Packaging 1 - Height (m) | 0.145m |
| Packaging 1 - Length (m) | 0.385m |
| Packaging 1 - Qty | 1100 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.01647m³ |
| Packaging 1 - Weight (kg) | 2.7826kg |
| Packaging 1 - Width (m) | 0.295m |
| Packaging 3 - Height (m) | 0.15m |
| Packaging 3 - Length (m) | 0.4m |
| Packaging 3 - Qty | 1100 |
| Packaging 3 - Type | Box |
| Packaging 3 - Volume (m³) | 0.018m³ |
| Packaging 3 - Weight (kg) | 3.1516kg |
| Packaging 3 - Width (m) | 0.3m |
| Packaging 4 - Height (m) | 1.194m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 61600 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.146m³ |
| Packaging 4 - Weight (kg) | 197.49kg |
| Packaging 4 - Width (m) | 0.8m |
