Wiring duct 40x80 mm, 2 m, PVC, blue
Art.-No. 181-10207 | HTWD-PWB-40X80-PVC-BU

Copied
This product is not available anymore.
  • Blue colour to identify intrinsically safe wiring
  • Wide slots suitable for large-diameter wires
  • Wide fingers provide additional wire support
  • Smooth, burr-free edges protect installers from injury and wires from damage
Show more

Request your individual offer now

Application HelaDuct HTWD-PWB blue wiring ducts are used to identify intrinsically safe wiring, for instance in chemical plants or anywhere where explosive gases may be present.
Colour Blue (BU)
Material Polyvinylchloride (PVC)
PART DESCRIPTION HTWD-PWB-40X80-PVC-BU
Pack Cont. 32m
Package Content packed in Box
Product Family HelaDuct HTWD-PWB Wiring Ducts for intrinsically safe wiring (metric sizes)
Product Group Blue PVC Wiring Ducts
Short Description Wiring duct 40x80 mm, 2 m, PVC, blue
Type HTWD-PWB-40X80
Height (H) 80mm
Length (L) 2m
Weight/Unit 0.543kg
Width (W) 40mm
Width (W2) 8mm
Width (W3) 12mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V0
Hazardous Goods No
Operating Temperature -5 °C to +65 °C
ROHS compliant Yes
Specifications
Country of Origin IT
Customs Number 39259020
GTIN-13 / EAN 4031026566290
Packaging 3 - Height (m) 0.2m
Packaging 3 - Length (m) 2.03m
Packaging 3 - Qty 32
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.0812
Packaging 3 - Weight (kg) 17.876kg
Packaging 3 - Width (m) 0.2m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 640
Packaging 4 - Type pallet
Packaging 4 - Weight (kg) 378.52kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000012
ETIM 8.0 Key EC000012
ETIM 9.0 Key EC000012
UNSPSC Key 39131712
